Polylux / Transmotor - 99 kVA 400 Volt / 230 Volt transformer 99 kVA

3881-polylux33kva

Used

Polylux / Transmotor  -  99 kVA  400 Volt / 230 Volt transformer 99 kVA

3 identical units in stock

More details

  • Get a Quote NOW
  • Product Request:


    Polylux / Transmotor - 99 kVA 400 Volt / 230 Volt transformer 99 kVA

    Polylux / Transmotor - 99 kVA 400 Volt / 230 Volt transformer 99 kVA

    Polylux / Transmotor  -  99 kVA  400 Volt / 230 Volt transformer 99 kVA

    3 identical units in stock

    do not include special characters

    * Required fields

    Cancel

    Data sheet

    ManufacturerPolylux / Transmotor
    Year2008
    Other 3 x 33 kVA transformers sold as a set - total 99 kVA @ 230 Volt - 50/60 hZ
    Amps400V - 82,5 A
    VoltPrimary: 400 Volt - Secondary 230 Volt
    HZ50/60
    kVA3 x 33 kVA, total 99 kWA
    ClassAccording to DNV

    More info

    Polylux / Transmotor  -  99 kVA  400 Volt / 230 Volt transformer 99 kVA

    Rating:

    33kVA

    Input voltage:

    400V

    Output voltage:

    230V/√3 à to connect the three transformes making a Dy connection

    Frequency:

    50/60Hz

    Ambient temperature:

    45°C

    Protection degree:

    IP-23

    Cover:

    Metal enclosure (epoxy polyester painted, RAL 7032)

    Cooling:

    ANAN

    Insulation:

    Class H - 180°C

    Windings:

    Class HC - 200°C

    Protection:

    Safety class I

    Test voltage:

    3kV (1min, 50Hz)

    Includes:

    Lifting eyebolts

    Remarks:

    According to DNV
