Polylux / Transmotor - 99 kVA 400 Volt / 230 Volt transformer 99 kVA

Rating:

33kVA

Input voltage:

400V

Output voltage:

230V/√3 à to connect the three transformes making a Dy connection

Frequency:

50/60Hz

Ambient temperature:

45°C

Protection degree:

IP-23

Cover:

Metal enclosure (epoxy polyester painted, RAL 7032)

Cooling:

ANAN

Insulation:

Class H - 180°C

Windings:

Class HC - 200°C

Protection:

Safety class I

Test voltage:

3kV (1min, 50Hz)

Includes:

Lifting eyebolts

Remarks:

According to DNV
