20 meter SWATH survey vessel https://mship.no View larger
Previous Next

20 meter SWATH survey vessel

vsl2024021

Used

20 meter SWATH survey vessel

More details

    • Data sheet

    Manufacturer20 meter SWATH survey vessel
    Model20 meter Swath Catamaran
    Year2014
    Fuel TypeDiesel
    ClassNorwegian maritime Authority
    OtherYard: CTRUCK LTD, Essex, UK.
    Weight32 Tonnes
    Passengers12
    Length Overall LOA Meter20,2 meter
    Molded Breadth Meter7,5 meter
    Design Draft Meter1,47 meter
    Draft (Maximum) Meter1,9 meter
    Cargo Deck Area:Fwd deck space 37m² max. Aft deck space 34m² max
    Deck Cargo Capacity:16 ton
    Fuel Oil:4000 liter
    ACCOMMODATIONS:Galley, shower, toilet.
    Main Engines:2 x 650 hp Cummins QSM 11
    Total Propulsion HP:1300 hp
    Propulsion:2 x Rolls-Royce 36 A3
    LIFESAVING EQUIPMENTAccording to requirement.
    Deck strenght m ²1t/m²
    Maximum speed19 knot
    Economical speed15
    Fuel consumptionabt 54 liter / hr @ survey speed 10 knot. abt 20 litre / hr @ survey speed 5 knot
    ROVSperre SUB-fighter 10K ROV, Max depth 1000 m, 1000m tether
    stabilizer systemNaiad Dynamics hydraulic stabilizers

    More info

    20 meter SWATH survey vessel with ROV, Multibeam and Sub bottom profiler.

    The SWATH hull form is designed to cut through the waves rather than ride over them, improves data accusation and transit comfort.

    The Naiad Dynamics hydraulic stabilizers are the industry standard for superior performance and reduce the pitch, roll, yaw motions.

    KEY CAPABILITIES

    INTERNAL EQUIPMENT

    Year Built

    2014

    ACCOMMODATION Fully air-conditioned, personalized suspension seating for all passengers and crew., lookers shelving for surveyors bags, microwave, fridge, hot water, charging area.

    Class

    MCA Category 2

    NAVIGATION/COMMUNICATION EQUIPMENT

    Hull Material

    Resin inf. Composite

    Radar

    SIMRAD x 2 Broadband

    Passengers 12

    Crew 2-4

    Electronic chart

    SIMRAD x 2 NSS12

    DIMENSIONS

    AIS

    Length overall 20m

    Fwd deck space 40m2

    Compass Simrad HS70 Sat + SilvaMagnetic

    Beam 7.8 m

    Aft deck space 12m2

    Depth sounder Simrad x1BSM-1

    Draft 1.49 – 2.06m

    Crew finder Sea Marshall SAR finder

    VHF Sailor 6222 DSC VHF x 2

    MACHINERRY

    Main engines

    Cummins QSM 11

    DECK EQUIPMENT

    Rolls Royce 36 A3

    Crane front deck HMF Handy 260

    Auxsillery

    Cummins Onan

    A-frame aft deck Towing

    PREFORMANCE DATA

    WAVE HIGHT LIMITATION

    Max speed

    22kts

    Transit Significant 1.75m Max 2m

    Service speed

    19kts

    Survey speed

    5kts

    TANK CAPACITIES

    WIND SPEED LIMITATION

    Fuel 4.000l

    Fresh water 340l

    TotalFuel use/service speed

    220l/h

    Total Fuel use/survey speed

    30l/h

    Survey equipment:

    • Kongsberg EM 2040P Dual Swat
    • Kongsberg Side Scan Sonar
    • Kongsberg Seapath 130 m
    • Kongsberg MRU 5
    • Eiva Navi Pack
    • Eiva Naviscan
    • Eiva Navimodel
    • Sperre 10K ROV, m.1000m tether.
