194' AHTS Built 2006 https://mship.no View larger
Previous Next

194' AHTS Built 2006

VSL2019-49382475

Used

194' AHTS Built 2006

More details

    • Data sheet

    Year2006
    HP5150
    Length Overall LOA Meter59,23
    Length between Perpendicular Meter52,50
    Molded Breadth Meter14,95
    Design Draft Meter4,95
    Molded Depth Meter6,10
    Cargo Deck Area:350 m2
    Deck Cargo Capacity:500 metric Ton.
    Deadweight Tonnage:1364 Metric Ton
    Gross tonnage ITC (registred)1677 Metric Ton
    Net Tonnage ITC (registred)503 Metric ton
    Fuel Oil:540 M3
    Tow Pins:2 x Electro-Hydraulic with turntable top flaps
    Fresh Water M³360 M3
    Stern Roller:4,5 m L x 1,60 m (dia), SWL 180 metric ton
    Ballast M³Ballast/Drill water 400 M3
    Dry Bulk:Cement tank 187 m3 (4 x 46,72 m3)
    Liquid Mud:370 m3
    ACCOMMODATIONS:4 x1 men +3x2 men + 8x4 men. total 42 men. All cabins fully air-conditioned & c/w attached washroom.
    Main Engines:2 x Caterpillar 3516 - 2 x 1920 kW (2575 hp) @ 1600 rpm
    Bow Thrusters:1 x 325 kW electric Kawasaki KT55B3 tunnel type witt CPP propeller - 5,6 ton thrust.
    Total Propulsion HP:5150
    Propulsion:2 x CPP Berg/Caterpillar with kort Nozzle
    Ship’s Service Generators:3 x 340 kW @ 1500 rpm Caterpillar 3408 coupled with Leroy Somer LSAM. 1L9 alternators rated 320 kW/415V 50 HZ
    Tugger:2 x 10 mt @ 15 m/min electro/hydraulic Mentrade MM1022-HUW. Drum capacity: 220 MLenghth x 22 mm Dia SWR
    Shark Jaws:1 set electro-hydraulic Karmfork - SWL 300 m/t
    AHTS Winch:2 x electro-hydraulic double drum. Mentrade MM1022-AHTW. 150 m/t @ 6.o m/s 1 st. layer. Static pull: 165 m/t @ 1 st. layer. Brake capacity: 200 m/t static @ 1 st. layer.
    LIFESAVING EQUIPMENTSOLAS
    Deck strenght m ²7,5 ton
    Firefighting:FiFi 1 with all around water curtain.
    Fire pump2 x 1550 m3 @ 13 Bar. Unitor SFP 250x350
    Monitors 1 x 300-1200 m3, water/foam Unitor FFS1200LB + 1 x 1 x 1200 m3, water Unitor FFS1200LB .
    Maximum speed13 knots
    Economical speed10 knots
    Fuel consumption19 m3/24 hours @ max speed - 12 m3/24 hours @ econ speed.
    Bollard pull65 Metric ton

    More info

    194' AHTS Built 2006

    Two identical sister vessels available, the oher vessel is built 2005. Click HERE to see the sister vessel.
